| Model | SK7/11-3317/3320/3323 | SK7/11-2517/2520/2523 | SK7/11-2017/2020/2023 |
| Effective cutting range | 3.3X1.7m | 3.3X2m | 3.3X2.3m | 2.5X1.7m | 2.5X2m | 2.5X2.3m | 2X1.7m | 2X2m | 2X2.3m |
| Length | 6.8m（加长为7.5m) | 6.0m | 5.3m |
| Total weight of equipment | 3.6T | 3.8T | 4T | 3.3T | 3.5T | 3.7T | 3.1T | 3.3T | 3.5T |
| Width | 2.45m | 2.75m | 4.2m | 2.45m | 2.75m | 3.05m | 2.45m | 2.75m | 3.05m |
| Height | 1978mm/1988mm |
| Table height | 800-850mm |
| Effective cutting height(after vacuum adsorption) | 70/110mm |
| Power supply | 三相 380V/50Hz |
| Total installed capacity | 25kW |
| Average power consumption | 12kW |
| Airsource(dry and clean compressed air) | 0.5-0.6MPa 160L/min |
| Maximum acceleration | 80m/min |
| Average cutting speed | 15m/min |
| Maximum acceleration | 1g |
| Maximum vibration frequency | 4000r/min |
| Blade specifications | 高速工具钢 SKH9:SK7 365x8.5x3/2.4/2 |
| Operating system | WINDOWS |
| CAD compatible | CUT、PLT、DXF、GGT、ISO、GBR |
| Maximum vacuum negative pressure | 负压 18-22kpa |
