| Pressurization mode | Pneumatic double roll pressure inlet belt extension | Pneumatic double roll pressure inlet belt extension | Pneumatic double roll pressure inlet belt extension |
| Max.bonding width | 900mm | 1000mm | 1200mm |
| Operating speed of conveyer belt | 0-8m/min | 0-8m/min | 0-8m/min |
| Bonding pressure | 0-0.4MPa | 0-0.4MPa | 0-0.4MPa |
| Bonding temperature | ≤ 190° C | ≤ 190° C | ≤ 190° C |
| Upper belt width*length | 900×2700mm | 1000×2700mm | 1200×2700mm |
| Bottom belt width*length | 900×2820mm | 1000×2820mm | 1200×2820mm |
| Exit section conveying width*length | 850×1570mm | 950×1570mm | 1150×1570mm |
| Heating Area | 1050mm | 1050mm | 1050mm |
| Electric heating power | 14.6kW | 15.7kW | 18kW |
| Compressed air pressure | 0.7MPa | 0.7MPa | 0.7MPa |
| Pressure adjusting mode | Pneumatic | Pneumatic | Pneumatic |
| Power supply | 380V/3PH/50Hz | 380V/3PH/50Hz | 380V/3PH/50Hz |
| G.W. | 500kg | 530kg | 600kg |
| Out line dimension (L*W*H) | 2540×1460×1513mm | 2540×1506×1513mm | 2640×1760×1513mm |
| Packing size | 1630(1730)(1830)×1690×1580mm | 1630(1730)(1830)×1690×1580mm | 1630(1730)(1830)×1690×1580mm |
