| Model | DX-1818 | DX-1820 | DX-1822 |
| Effective cutting range | 1.8*1.8m | 1.8*2.0m | 1.8*2.2m |
| Length | 4.9m |
| Total weight of equipment | 3.1T | 3.4T | 3.7T |
| Width | 2.45m | 2.75m | 3.05m |
| Height | 1978mm/1983mm |
| Table height | 800-850mm |
| Effective cutting height(after vacuum adsorption) | 90mm |
| Power supply | 三相 380V/50Hz |
| Total installed capacity | 26/36kW |
| Average power consumption | 12/15kW |
| Airsource(dry and clean compressed air) | 0.5-0.6MPa 160L/min |
| Maximum acceleration | 110m/min |
| Average cutting speed | 20m/min |
| Maximum acceleration | 1.5g |
| Maximum vibration frequency | 6500r/min |
| Blade specifications | 高速工具钢 SKH9:DX9 365x8.5x3/2.4/2 |
| Operating system | WINDOWS |
| CAD compatible | CUT、PLT、DXF、GGT、ISO、GBR |
| Maximum vacuum negative pressure | 负压 -22kpa |
